IEC 61850 Vendor Independent Systems Engineering

FAST recently re-engineered a multivendor IEC 61850 Station Bus Substation Automation System using a top down engineering approach for system specification and integration. The project was a proof of concept put forward to a utility to replicate an already in service design to highlight engineering design efficiencies. The following is an outline of the process of engineering the system and resulting CID files through HELINKS System Tool Set. The results were then compared to the utility’s commissioned CID files which were created using multiple Vendor Tools.

SCADAIEC 61850HELINKS STSEngineering11-09-2015
Automation Design, Communications and SCADA Resources

FAST Engineering partnered with Titan ICT (Titan) to deploy a team of highly experienced SCADA personnel for the communications design, modem configuration, SCADA design and SCADA testing support for intelligent devices in Ergon Energy's distribution network. The distribution devices were to include Automatic Circuit Reclosers, Remote Sectionalisers, Remote Load Break Switches and Line Fault Indicators.

SCADAEngineering31-07-2015
What is IEC 61850

IEC 61850 is a standard for the design of electrical substation automation and is a part of the International Electrotechnical Commissions (IEC) Technical Committee 57 (TC57) architecture for electric power systems.The IEC 61850 standard is an innovative approach to substation automation that will result in improvements in both performance and costs in protection systems and data acquisition.The standard defines the communications interfaces, provides object models for common substation plant and functions and standards within a substation.

SCADAIEC 61850Engineering01-05-2015
Project - Latrines at Three Centres

FAST Engineering funded a project to provide new latrines at three centres in the Yirgalem region of Ethiopia.

Community01-05-2015
Top Down vs Bottom Up Engineering

Top down and Bottom up Engineering are two different design methodologies used for design of complex engineering systems. You probably use one, both or a combination of these methods on a daily basis without consciously thinking about it. Both design methods have their individual advantages and disadvantages when applied to Systems Engineering.Understanding the differences can help select the most cost effective approach or, if the approach has already been selected for you, help you identify what issues you are likely to expect.

In short bottom up engineering is probably simpler and initially more flexible to change. It allows a faster initial learning curve on the basics and can be great whilst getting some base level knowledge. Top down engineering is more reusable and repeatable with lower whole of life costs. It has greater initial complexity but enables faster design iterations with less ongoing engineering requirements. Perhaps it's a kick back to our university days ("Bottoms Up!") or perhaps because engineers like solving problems more than planning on solving problems, that the Bottom Up approach is our usual first tactic. However bottom up engineering becomes more difficult and costly to change the further into a design you go.

Like all good dance floors, the selection process should start with some "Man in the Mirror" moments. One of the first parts of the process is identifying "Where are we now?" in terms of your engineering life cycle and business knowledge base. For example IEC 61850 is great for repeatable and reusable engineering. If I have an ageing asset and one legacy relay has failed, going through the process of System Requirements Specification to upgrade it to a 61850 based design is probably not viable. Alternatively if you are replacing a switchyard a Top Down design that reduces ongoing engineering and costs over whole of life for the asset is ideal. If your business doesn't have the knowledge base or experience in Top Down Engineering, Fast specialises in this aspect of design and can help specify your required system.

Engineering01-05-2015
What is System Specification for IEC 61850

System Specification for IEC 61850 is an optional component and is used to specify from a high level "what" the system should look like and "what" functions it should perform. It allows a standards based approach to design that provides a framework for creating repeatable and reusable engineering. It is not interested so much in the "how" a system is implemented- albeit the how will often be in mind during this phase to some extent. Given that the "what" is specified without the "how" it is the enabler of IEC 61850's desire for interoperability and interchangeability. The

"Top down engineering" approach in System Engineering begins with the creation of a comprehensive System Specification.Thorough detail in the System Specification stage reduces engineering time and can simplify thelater "System Integration" Stage.

SCADAIEC 61850Engineering01-05-2015
